4.6.5.2 Motherboard with CAN-Bus

Designation

Terminals

Interface on the system

GPRS

White plug

dev/usb/ttyUSB0

Bluetooth

Display connector

dev/usb/ttyUSB1

GPS

4-7

dev/ttyS3 (not changeable)

Printer

8-13

dev/ttySM0

RS232

66-69

dev/ttyS4

RS485

128-131

dev/ttyS2

RS232_1

132-137

dev/ttySM1

RS232_2

138-141
