Bartec MAK TIGER 3003 Service Manual

Measuring system MAK E-TIGER 3003
68
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
6.11 Technical data
Measuring-system-specific data
Voltage rating for electronics
DC 24 V (9 - 36V) from power supply
Operating voltage measuring system
AC 400V, 16 A CEE
Power connection
AC 400V, 16 A CEE plug, 3L+PE 6h
Emergency mode
Power supply 24 V (valves), 16 A CEE three-phase AC (cen-
trifugal pump)
Drive
7.5 kW IE3 electric motor, frequency inverter controlled
Self-supply electronics
DC 24 V, max. 40 A
Control cabinet heater
DC 24 V; 150 W
Speed
approx. 2000 rpm
Compressor (optional)
250 l/min at 6 bar; max. 10 bar
Compressed air Ejector
5.6 bar (service unit)
Valve terminal
6 bar (service unit)
Compressed air level
4 bar (service unit), filter 0.01 µ
Air consumption ejector
approx. 500 nl/min @ 5.6 bar
Suction power
type. 1300 l/min. under good intake conditions
Suction and pressure side connections
ND 3“ (optionally ND 65 or DN 50) milk pipe screw fitting
Connections ejector exhaust air/ empty-
ing
ND 25 or ND 50) milk pipe screw fitting
Accuracy
≤ 0.5 %
Lowest intake rate
200 l with 3“ MIF
CIP
yes;

max. 85°C @ 2 bar
Mechanical data
Material for milk line
V
2
A; PTFE; PEEK, POM
Dimensions
See scale drawing
Weight including sampling and stand
Approx. 600 kg
Ambient conditions
Operating temperature
0 to +85°C medium; -20 to +50°C electronics
(frequency inverter required for cold start < 0°C heat-up time)
Storage temperature
-20 to +60°C (without fluid)
Protection class for measuring system
IP 55
Protection class for control cabinet
IP 55
