Measuring system MAK E-TIGER 3003
67
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
35
36
37
38
Sampler motor for tank sample, phase A
Sampler motor for tank sample, phase B
Sampler motor for tank sample, phase C
Sampler motor for tank sample, phase D
bl
br/wt
gn/yl
gr/pi
Sampler motor for
whole tank sample
39
40
41
+24 V on-board power supply from terminal 54
AGND on-board power supply from terminal 55
+44 V operating voltage for sampler motor for individual
samples, supply from terminal 56
rd 1.5 mm²
bl 1.5 mm²
bk 1.5 mm²
Terminal 54
Terminal 55
Terminal 56
42
43
44
45
46
47
48
49
50
51
Signal M Up, bottle lifting motor
Signal M Down, bottle lifting motor
Signal M Out, magazine discharge motor
Signal M In, magazine infeed motor
Signal M Star, star drive motor
Signal P Star, self-holding contact for star drive
Ground reference potential for P-Star signal
Signal P Star, check-back signal
+ 24 V on-board power supply for bottle drive
GND on-board power supply for bottle drive
Shield connection for bottle drive cable
bn
rd
yl
gn
pi
vi
grwt
Wire jumper
bk
bnwt
IN 7 (Terminal 32)
52
53
Shield connection for on-board power cable
+ 24 V on-board power supply
GND on-board power supply
-7F1:1
-X3:12
54
55
56
+ 24 V on-board power output
OGND on-board power output
+ 44 V operating voltage output for Sampler 1
rd 1.5 mm²
bl 1.5 mm²
bk 1.5 mm²
Terminal 39
Terminal 40
Terminal 41
