Bartec MAK TIGER 3003 - 16 Flow Meter MID Type 6823-X; Technical Data

Flow Meter MID type 6823-x
99
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
16 Flow Meter MID type 6823-x
Order no .: see technical data
Magnetic-inductive MID flow rate meters, type 6823-x, are precision sensors
designed to measure the volume of electrically conductive liquids. Their robust
build and material specification make them particularly suitable for flow meas-
urement applications in areas subject to strict hygiene standards, such as the
measurement of milk quantities on collection vehicles. All the products can be
calibrated.
16.1 Technical data
Specifical Data
Measure range
100 l/min to 2000 l/min, depending on version see table
Accuracy
≤ 0,3 % (In the above measuring range)
Conductivity
> 5 µS/cm
Pressure
max. 10bar
Electrical Data
Auxiliary voltage
24V DC ±15%
Power consumption
max. 6W
Outputs
PNET/ 3-Chanal (open collector)
Pulse output
0 – 1000 Hz
volumetric measurement signal for counter
indication of the current flow
3 channel pulse output
as 1 channel pulse output with direction signal and error signal
as 2- or 3 channel pulse output
Analog output
4 ... 20 mA (external source)
Connection
7 m connection cable10x0,25mm² shielded, with open ends
PG11 cable bushings, internal screw-type terminals.
Connection cable assignment
MID-terminal
Wire color
Signal
1
pk/gy
+24V
2
Shield
GND
7
wh
+ Display
8
bu
- Display
13
bn
S
B
A
P-NET
14
gn
15
ye
16
vt
Output 3
GND
Output 3
17
bk
