Flow Meter MID type 6823-x
100
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Connection three-channel pulse
output
MID
(terminal)
1 channel
2 channel
90°
3 channel
120°
3 – 4
Phase 1
Error
Phase 1
18 – 17
Error
Phase 1
Phase 2
16 – 17
UP/DOWN
Phase 2
Phase 3
Ambient conditions
Admissible operating temperature
-10 … +50°C
Admissible storage temperature
-10 … +50°C
Protection class
IP 67
Mechanical data
Dimensions
See drawing
Weight
Approx 5kg
Material
Stainless steel teflon coated, stainless steel, PPO Noryle
Connection
Clamp NW 2“, NW 2,5“, NW 3“
ISO 2852
