Bartec MAK TIGER 3003 - Technical Data

V2000 Modul, type 6757-14 Ser. A
108
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
17.1 Technical data
Specifical Data
Normal conditions
23 ± 2 °C
Elektrical data
Elektronics
Operation voltage
DC 24 V ± 5 %
Reversible fuse 1,1 A
Current consumption
100 mA
Operating voltage of sensors
DC 24 V ± 5 % (internal voltage)
Reversible fuse 50 mA for each sensor input
Operating voltage I/O and PWM
DC 24 V on-board supply system
Reversible fuse 2 x 4A (4 outputs each)
Reversible fuse 3 A für PWM
Current consumption I/O
Max. 8 A
Outputs switch function
Quantity
2 x 4
Galvanic isolation
Optocoupler 2500 VRMS
Frequency
Max. ≤ 10 kHz
Switching level
0/24-V on-boarder supply system
Current per output
1A DC, short-circuit-proof
Switch type
High side solid state (MOSFET)
Frequency inputs
Frequency-
imp
MID input
0 – 1 kHz (low side), U
s
DC 24 V UB
Frequency
-imp
rotary encoder input
0 – 1 kHz (low side), U
s
DC 24 V UB
Analogous inputs
Dipstick
0 – 20 mA, U
s
DC 24 V, 0,25 % resolution
Pressure
4 – 20 mA, U
s
DC 24 V, 1 % resolution
S1 (foam)
0 – 2,5 V, U
s
DC 24 V, 1% resolution
S2 (reserve)
0 - 2,5 V, US DC 24 V, 1 % resolution
Ambient conditions
Operating temperature
- 10 ...+ 50 °C
Storage temperature
- 20 ...+ 70 °C
Protective type
IP 20
Mechnanical data
Dimensions
Approx. T 190 x H 145 x B 55 mm
Material
Aluminium nature (AlMg 3)
Weight
Approx. 500 g
