Bartec MAK TIGER 3003 - Suggested Design of Vacuum Container

Measuring system MAK TIGER 3003
40
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
5.16 Suggested design of vacuum
container
Not included in BARTEC BENKE delivery scope.
Note:
- Fasten the vacuum container via vibration decoupling (rubber damper)
- Cut milk sensor 2 to a length of 15 cm and strip 3 cm of insulation from the bar.
