Bartec MAK TIGER 3003 - 19 Barcode Reading Unit Type 6723-10; Technical Data

Barcode reading unit type 6723-10
115
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
19 Barcode reading unit type
6723-10
Order no.: U96417672310
The bar code reading unit type 6723-10 can be used to decode the pulse se-
quence of a connected bar code reader and to transmit the data via P-NET
(RS485) for further processing.
Bar code readers with TTL output level can be connected, where "bright" cor-
responds to low and "dark" corresponds to high.
The bar code reading unit will accept the following four types of bar code if
they contain the mandatory number of alphanumeric characters.
Bar code
Number of characters
Interleaved 2 of 5
4 … 32
UPC/EAN
Fixed length
Codabar
1 … 32
Code 11
1 … 32
Code 39
1 … 32
Code 128
1 … 32
MSI Code
1 … 32
The bar code reading unit is set at the factory to read bar codes of the "Inter-
leaved 2 of 5" type with the mandatory 10 characters. The default operating
mode is "continuous scanning".
19.1 Technical data
Electrical data
Auxiliary power
Rated voltage: DC 24 V  20 %
Rated output: 1.5 W (excluding bar code reader, excluding heating)
Fuse
2 x 1 A (time-lag)
Fieldbus interface
P-NET (RS485), max. line length 300 m
Electrical connection
Connection
Screw terminals 0.2 … 1.5 mm²
3 x cable fitting PG9, cable diameter 4 … 8 mm
Bar code reader
Scanner with TTL-compatible output, "bright"  low, "dark"  high
Bar code reader heater
12 or 24 V DC, max. 1.6 W
Bar code reader electronics
5 V DC, max. 50 mA
Ambient conditions
Operating temperature
- 20 ... + 60° C
Storage temperature
- 40 … + 85° C
Climate class/protection type
JUF / IP 65
Mechanical data
Housing specification
Die-cast aluminium
Dimensions
120 x 122 x 80 (mm)
Weight
Approx. 12 N  1.2 kg
Installation position
Optional, but cable inlets must not face upwards
