Bartec MAK TIGER 3003 - Wiring; Electrical Terminal Assignment

ULTRASAMPLER® sample collection system
165
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
26.3.3 Wiring
The FLM is supplied as standard with 5 m of cable which is connected as
shown on the diagram below. Please follow the directions for use of the fol-
low-on device when wiring.
26.3.4 Electrical terminal assignment
Terminal block
Signal
Colour
6771-31
3
- Flow 4 - 20 mA
bk
5
3
+Flow 4 - 20 mA
vt
4
2
- Level 0.3 - 2.5 V
bn
5
2
+ Level 0.3 - 2.5 V
ye
3
4
P-NET A
wh
Insulated
4
P-NET B
bu
Insulated
4
P-NET S
---
---
1
- 24 V DC (GND)
Shield
2
1
+ 24 V DC
pk/gy
1
Please insulate any non-required conductors individually.
