Bartec MAK TIGER 3003 - Technical Data; Wiring

ULTRASAMPLER® sample collection system
177
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
26.7.1 Technical Data
26.7.2 Wiring
Proximity switch
NPN Order.No. U495593
Ground switching
Controller 1)
MAK compact-Con-
troller
6942-10
US-Controller
6771-31
brown (bn) + 24V_S
IN 1 – 8
+ 24 V clamp 25
blue (bu) AGND
IN 1 - 8
GND clamp 34
black (bk)
Free inputs IN 1 - 8
Free inputs
IN 1 – 8
clamp 26 ... 33
Proximity switch
PNP Order.No. U496004
Positiv switching
Controller 1)
MAK Compact-Con-
troller
6942-10
I/O-Box 6753,
Inputs
brown (bn)
IN 1 – 8
+ 24 V
blue (bu)
IN 1 - 8
GND
black (bk)
Free inputs IN 1 - 8
Free inputs
IN 1-8
Note:
If a ground-switching proximity switch is to be connected to a device (eg I / O
box 6753) with posi-tive-switching inputs, this can be done by interposing the
constant current module Type 6753-302 as a "pull up" between + 24 V and the
corresponding input (see Fig. 1)
The digital inputs of the compact controller 6942-10 are configured as "positive
switching" by de-fault.
By changing the configuration (see Type 6744-10) each input can be customized
also be switched to "mass switching".
Electrical data
Operating voltage
24 V DC
Ambient conditions
Operating temperature
-10 … +50 °C
Store temperature
- 10 … + 70 °C
Protective system
IP 68
Mechanical data
Construction
Fixed and mobile parts made of stainless steel, sliding disks
made of Teflon; inductive proximity switch is screwed in and
tightened
Weight
ca. 7 N  0,7 kg
Usable sample bottles
50 ml Sample bottles with triple slotted sealing plug
