V2000 Modul, type 6757-14 Ser. A
110
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Modul: V 2000, Type: 6757-14
Clamp
Designation
LAS
dipstick
Pressure sensor
6703-15
S1-foam se-
parator
6703-15
S2-MID
6823-x
MID
Proximity
switch
Snr. 495595
Hydraulic
valve
(PWM)
501
+ 24V
bn
502
I + (Peilst.)
ye
503
I -
gy
504
- (GND)
bu
505
+ (24V DruckS)
wh
506
-
bn
507
+ (24V)
pk
508
- (GND)
ye
509
In (Signal S1)
gy
510
+ (24V)
pk
511
- (GND)
ye
512
In (Signal S2)
gy
513
+ (24V B)
514
IN1 (Signal)
515
-
516
+ (24V B)
517
IN2 (Signal)
518
-
519
+ (24V B)
520
IN3 (Signal)
521
-
522
+ (24V B)
523
IN4 (Signal)
524
-
525
+ (Signal MID)
vt
526
- (GND B)
bk
527
+ (24V B)
bn
528
IN_Dreh (Signal)
wh
529
- (GND B)
bu
530
I_OUT + (0-20 mA)
531
I_OUT -
532
unbelegt
533
PWM+(Signal)
bn
534
PWM-(GND B)
bu
535
OUT_1+ (24V B)
536
OUT_1- (GND B)
537
OUT_2+ (24V B)
538
OUT_2- (GND B)
539
OUT_3+ (24V B)
540
OUT_4+ (24V B)
541
OUT_5+ (24V B)
542
OUT_6+ (24V B)
543
OUT_7+ (24V B)
544
OUT_7- (GND B)
545
OUT_8+ (24V B)
546
OUT_8- (GND B)
547
UB+
548
UB-
