Compact Controller TIGER Type 6942-10 Serie C
8
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Measuring system interface
Current inputs
3 x DC 24 V, 0/4 - 20 mA
Voltage inputs
2 x DC 24 V, 0 - 4V
1 x DC 12 V, 0 - 4V
Temperature sensors
2 x Pt 100, 4 conduction
Pulser input
24V stabilized, max. 1kHz
PWM-output
24V stabilized, max. 400Hz
Analogue output (optional)
0/4 - 20 mA, R
B
max. 500 Ω, 10 bit galvanically isolated
Voltage outputs
16 x plus schaltend 1 A, 24 V stabilisiert (3 A total)
Digital inputs
8 x optically isolated, input resistance 2.6 KΩ, bipolar, solid state
Pulse counting
3 channel max. 100 Imp/s, Input optically isolated 5 kΩ pull-up
Interface
Interface printer
RS 232, RxD, TxD, CTS, RTS, 115 K galvanically isolated
Interface Fieldbus
P-NET RS485, 76800 baud, galvanically isolated
Interface Bluetooth
Bluetooth 2.0 radio modul (Class 2), reach max. 20m
Interface CAN
CAN 2.0 A/B, 250kBaud
Communication profile: free protocol based on SAE J1939, FMS
CAN-Bus-termination: can be switched on and off
Other
RS485, Ethernet 100 Mbit (auf CPU), several RS232 (3x without hand-
shake, 1x with handshake)
Ambient conditions
Operating temperature
- 20 … + 50 °C
Storage temperature
- 25 … + 60 °C
Climate classification
ISF according to DIN 40050
Protective type
IP 65 according to DIN 40040
Mechanical data
Dimensions
See drawing
Material
Aluminium pressure die casting, coated blue
Front screen
PES
Weight
65 N (6,5 kg)
