ULTRASAMPLER® sample collection system
162
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Ordering details
Designation
Order number
Horizontal mounting (flat):
Flow Level Meter 2“, type 6826-10
U950 17 682610
Flow Level Meter 2,5“, type 6826-20
U950 17 682620
Flow Level Meter 3“, type 6826-30
302063
Mounting position
Vertical mounting (edgewise):
Flow Level Meter 2“ 90°, type 6826-11
U950 17 682611
Flow Level Meter 2,5“ 90°, type 6826-21
U950 17 682621
Flow Level Meter 3“ 90°, type 6826-31
304782
Mounting position
Note: Please mind flow direction (arrow on type plate) !
Accessories:
Sealing ring for clamp 2“
U495077
Clamp foldable 2“
U495080
Sealing ring for clamp 2,5“
U495059
Clamp foldable 2,5“
U495056
Sealing ring for clamp 3“
U495031
Clamp foldable 3“
U495065
