Measuring system MAK E-TIGER 3003
62
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
bl
-9U1:bl
-9A1:2
-W9
Ölflex-110
gnyl
3 x 4 mm² PE
Cooler, sample compart-
ment
1
-X4:1
+
2
-X4:2
-
-W10
Ölfl.100 5x2.5 VDE0293f
Shield
5x2.5 mm² PE
shield
-2A1:shield
Supply FC
gnyl
-X1:PE
-2A1:PE
bn
-2F1:1
-2A1:L1
sw
-2F1:3
-2A1:L2
gr
-2F1:5
-2A1:L3
bl
-W11
Ölfl.100 5x2.5 VDE0293f
Shield
-2A1:shield
FC power choke
gnyl
-2A1:PE
-2M1:PE
bn
-2A1:U
-2Z1:U1
bk
-2A1:V
-2Z1:V1
gr
-2A1:W
-2Z1:W1
bl
-W12
Ethernet Cat6
Shield
-8X1:shield
Ethernet connection
wtor
-8X1:1
or
-8X1:2
wtgn
-8X1:3
bl
-8X1:4
wtbl
-8X1:5
gr
-8X1:6
wtbn
-8X1:7
bn
-8X1:8
-W20
LiYCY 7x0.25 DIN47100
Shield
7x0.25 mm² shield
PNET barcode reader
unit
wt
bn
-9A1:S
-7A1:2S
gn
-9A1:B
-7A1:2B
yl
-9A1:A
-7A1:2A
gr
pi
-9A1:+
-7A1:2+
bl
-9A1:-
-7A1:2-
-W101
Ölfl.100
2x0.75VDE0293ov/2
br
2x0.75 mm²
-5A1:24
1
Solenoid valve for ejec-
tor
bl
-5A1:25
2
-W102
Ölfl.100 2x0.75
VDE0293ov/2
br
2x0.75 mm²
-5A1:26
1
Solenoid valve for
discharge
bl
-5A1:27
2
-W103
Valve terminal VM10
DIN47100
wt
25x0.5 mm²
-5A1:28
Valve terminal connec-
tion cable
br
-5A1:30
gn
-5A1:31
yl
-5A1:32
gr
-5A1:33
pi
-5A1:34
bl
-5A1:35
rd
-5A1:44
bk
-5A1:37
vi
-5A1:38
grpi
-5A1:36
rdbl
-5A1:46
wtgn
-5A1:29
brgn
wtyl
ylbr
