On the Camera Preview toolbar, click the Clear Blocking button.2.
Result: All masking are cleared from all BTSensors.
To manually mask a BTSensor view
In Motive, go to the Camera Preview window.1.
Result: What each connected BTSensor sees is displayed as a 2D image in the Camera View
window. If BTSensors are configured to see infrared sources, they appear as white objects.
On the Camera View toolbar, select the shape of the mask, either Rectangular Blocking or Circular2.
Blocking from the toolbar.
Result: You will create masks in the selected shape.
To mask the infrared interference areas inside the Camera View window of a BTSensor, click on one3.
corner of the interference while holding the left mouse button down and drag the mask to cover
the infrared interference.
Result: The infrared interference (white object) is covered in by a mask (red object). While
masked, the infrared source will not interfere with tracking.
Repeat for each instance of infrared interference. 4.
