SLIM 13E
SLIM 13E Diagram
Product ID
Model number: CAM-CAM-S13
Physical Characteristics
Mounting: 0.635 cm (1/4”)-20 tripod thread
Operating temperature: 0°C to +51°C (32°F to 123.8°F)
Case: Aluminum and Polycarbonate
Width: 6.86 cm (2.7”)
Height: 6.86 cm (2.7”)
Depth: 2.3 cm (0.9”)
Weight: 320 g (11.29 oz)
Lens & Filter
Stock lens: 5.5 mm F#1.8 (wide band AR coated)
Horizontal FOV: 56°
Vertical FOV: 46°
Optional Lens: 8.0 mm F#1.8 (wide band AR coated)
Horizontal FOV: 42°
Vertical FOV: 34°
Optional Lens: 3.5 mm F#1.8 (wide band AR coated)
Horizontal FOV: 82°
Vertical FOV: 70°
Adjustable focus with wave spring assist
850nm band-pass filter
850nm (Infrared) / 700nm (Visible) Filter Switcher
Image Sensor
Resolution: 1280 × 1024
Frame Rate: 30–240 FPS (100 FPS average usage)
