Layout of the Cue Module
Motive Input
In the Motive Input section, network settings are displayed showing the port and the input/output
connections to Motive.
Record
In the Record section, you can specify the Time Stamp Frame ID sequence to record by setting the start
and end Frames.
Frame ID: Specify the Frame time stamp data you want to record.
Start: In this box, type the Frame number where you will start the recording.
End: In this box, type the Frame number where you will end the recording.
Current Frame: Displays the actual Frames that are currently running.
Recorded: Displays the actual number of Frames that were recorded.
Start/Stop: Click this button, to start or stop the recording.
Note: You will not be able to Start before your Start Frame. The recording will also
automatically stop when you reach the end Frame.
Save To File: Click this button to save the recorded Frames as a .rec file to any location that you
choose.
Note: The Save To File button appears when a recording is completed. Once pressed a
browse window appears.
Chapter Content
In the Chapter Content section, you can select the recorded file that will be used in the Chapter that
you want to create.
File: Type the file name and path or click the browse button to locate and select the recorded
Frame.
Name: Type a name for the Chapter that you want to create.
Chapter ID: Type the number for the Chapter that you want to create (this corresponds to the
Chapter ID in the Main GUI).
Note: When the Main GUI enters Chapter 1, it sends a command to Cue to start playing
Chapter 1 as well (if in Show Mode). If the Main GUI enters a Chapter that does not exist in
Cue, then Cue will stop playing the current recording.
Loop: Select this checkbox to set the recorded file to play in a loop.
Delay (ms): Type the playback delay (in milliseconds) for the Chapter to wait after being triggered
to start playing data.
Recording Mode/Show Mode
In this section, you can toggle between Recording Mode or Show Mode.
Recording Mode: Saved files are created as Chapters and added to the table for editing and
playback.
Note: Click the Recording Mode button to toggle into Show Mode, which will display the list
