Record and Playback Tracking Data in
the Cue Module
The Cue Module is where you can record simulated tracking data and real-time tracking data in live mode
from Motive.
In the Cue Module, the tracking data are recorded as Chapters that are stacked as a series of cues which
can be recalled from the Main GUI in BlackTrax. The Cue Module follows the Chapter in the Main GUI in
BlackTrax.
To record cues from tracking data recorded in Motive
Note: By default,the Enable In and Enable Out checkboxes in the Motive Input section of Cue Module
are enabled and the network settings are displayed showing the port and the input/output connections to
Motive.
In Motive, go to the Recording view mode which will display the Timeline of the recorded file in the1.
Timeline section.
Open a recorded tracking data file (.tak) from Motive.2.
In Motive, identify the frame ID number where you want to start the cue that you will record.3.
In the Record section of the Cue Module, type the start frame ID number in the Start box of the4.
Frame ID section.
In Motive, identify the frame ID number where you want to end the cue that you will record.5.
In the Record section of the Cue Module, type the end frame ID number in the End box of the6.
Frame ID section.
In the Record section of the Cue Module, click Start.7.
In Motive, click the Play button in the Timeline section.8.
Note: You can type the start and end frame ID numbers in the preset boxes at the bottom of
the Timeline section in Motive.
In the Record section of the Cue Module, click Stop.9.
Result: The Save to File dialog box appears.
Click Save to store the file in your specified location.10.
Result: The recorded frame is saved as a chapter content file (.rec) which will be used to
create the stack of cues.
To create the chapters cue stack in recording mode
In the Chapter Content section of the Cue Module, type the file name and path of the recorded1.
Frame in the File box or click the browse button to locate and select the recorded Frame that you
want to create as a chapter in the cue stack list.
In the Chapter Id box, enter the number for the chapter you want to create. The Chapter ID number2.
will correspond and sync with the Chapter that you wish to recall and playback in the BlackTrax
GUI.
In the Name box, type the name that you want to add to the chapter that you will create.3.
Select the Loop checkbox to set the created chapter to play in a loop.4.
In the Delay (ms) box, you can type the length of time (in milliseconds) for the chapter to delay the5.
playback after it was triggered to start playing.
Result: The recorded Frames that were created as Chapters will be displayed in the table as
a stack of Chapter cues in series and sorted according to the Chapter ID number.
On the cue stack list of created Chapters, you can apply the following options:6.
Click Save List to save the current cue stack series of created Chapters as a BlackTrax Cue
