Requirements for Creating the Space in
BTWYSIWYG
To use BlackTrax you are required to create a virtual representation of the Space in BTWYSIWYG. This
virtual Space will possess vital information that BlackTrax requires as follows: what the dimensions and
tracking area of the Space are, what objects or people you want BlackTrax to follow (Trackables), and
information on devices in use (e.g., fixtures). This section will guide you on creating the Space in
BTWYSIWYG and aspects that must be included.
To create the BTWYSIWYG file for tracking with moving fixtures in BlackTrax, follow these
mandatory steps
Define a common origin position in the Space. (Default set in template file.)1.
Create and patch Trackables to a motion universe and assign avatars. (Default set in2.
template file.)
Hang moving fixtures approximately where they will be in the venue with the correct orientation.3.
Patch fixtures to DMX universe and assign Spot IDs.4.
Patch DMX universes to console. (Default set in template file.)5.
Patch all created universes to BlackTrax. (Default set in template file.)6.
Save the BTWYSIWYG project. 7.
Export the BTWYSIWYG project for use with BlackTrax. (Default set in template file.)8.
Tip: Some of the required steps are set by default when the BlackTrax Template file is used in
creating a BlackTrax Portfolio, or from the Templates section in BTWYSIWYG.
To create the BTWYSIWYG file NOT for tracking with moving fixtures, follow these mandatory
steps
Define a common origin position in the Space. (Default set in template file.)1.
Create and patch Trackables to a motion universe and assign avatars. (Default set in2.
template file.)
Patch all created universes to BlackTrax. (Default set in template file.)3.
Save the BTWYSIWYG project.4.
Export the BTWYSIWYG project for use with BlackTrax. (Default set in template file.)5.
Tip: Some of the required steps are set by default when the BlackTrax Template file is used in
creating a BlackTrax Portfolio, or from the Templates section in BTWYSIWYG.
BTWYG file with patched fixtures and a trackable
