Optional View Settings
Because every Space is different, there are certain BTSensor settings that will be unique. This section
provides guidelines on certain Motive settings which will create an accurate tracking environment.
Motive 2
To enable visualization of the tracking boundary
If the tracking boundaries of the Physical Space were enabled and defined, the limits can be visualized
after BTSensors have been calibrated.
In Motive, change the layout to Configuration preset. From the Layout menu, choose1.
Configuration.
Tip: You may click the drop-down box at the right-hand side of the main toolbar and click
Configuration from the drop-down menu of layout presets.
In the Application Settings window, click the Live Reconstruction tab.2.
On the Live Reconstruction tab, click the Advanced Options heading to open the Reconstruction3.
Bounds section.
On the Reconstruction Bounds section, click the Visible Bounds drop-down menu and click True.4.
Result: The set tracking boundary of the Space will be displayed in the Perspective View
window.
To save the take, choose Save Current Take or Save Current Take As from the File menu.5.
To save as a profile, choose Save Profile or Save Profile As from the File menu.6.
To disable visualization of the tracking boundary
In Motive, change the layout to Configuration preset. From the Layout menu, choose1.
Configuration.
Tip: You may click the drop-down box at the right-hand side of the main toolbar and click
Configuration from the drop-down menu of layout presets.
In the Application Settings window, click the Live Reconstruction tab.2.
On the Live Reconstruction tab, click the Advanced Options heading to open the Reconstruction3.
Bounds section.
On the Reconstruction Bounds section, click the Visible Bounds drop-down menu and click False.4.
Result: The set tracking boundary of the Space will not be displayed in the Perspective View
window.
To save the take, choose Save Current Take or Save Current Take As from the File menu.5.
To save as a profile, choose Save Profile or Save Profile As from the File menu.6.
Motive 1.10 or lower
To enable visualization of the tracking boundary
If the tracking boundaries of the Space have been defined, and enabled the limits can be visualized after
BTSensors have been calibrated.
Open the Reconstruction Properties window. To open the window, from the View menu, choose1.
Reconstruction Properties.
In the Reconstruction Properties window, in the Advanced Options section, under the2.
Reconstruction Bounds heading set the Visible Bounds field to True.
