Motive Project File
A BlackTrax project requires specific information (BTSensor, calibration and configuration) from Motive,
that is unique to every BlackTrax project. This information is required every time BlackTrax operates.
Motive 2
In Motive, recorded motion capture data is stored as a Take (.tak) file format, all application-related
configurations are saved onto Profile XML (.xml) files, and calibration data for each BTSensor position,
orientation and lens parameters are saved as standalone calibration CAL (.cal) file format.
In Motive, profile and calibration data are automatically saved into the ProgramData folder and
automatically reloaded when Motive is opened again.
In Motive, profile data is automatically saved once every five minutes and calibration data is
automatically saved whenever calibration is updated (such as in Continuous Calibration).
Multiple Take (.tak) files are automatically saved in a Session Folder which can be accessed from the
Data window.
To save a Take to a new location and/or using a new file name
In Motive, from the File menu, choose Save Current Take As.1.
Result: The Save Current Take As dialog box appears.
In the File Name field, type the name of the Take file.2.
Click Save.3.
Result: The renamed Take file will be saved in the selected location.
To save an existing Take file using the same location and file name
In Motive, from the File menu, choose Save Current Take.1.
Result: Only the recording of the wanding is saved after calibration.
Notes:
Save current take is automatically applied after ground plane calibration.
Use Export Camera Calibration from the File menu to save the calibration data.
See To export a calibration CAL file.
To save a Profile to a new location and/or using a new file name
In Motive, from the File menu, choose Save Profile As.1.
Result: The Save Profile dialog box appears.
In the File Name field, type the name of the Profile XML file.2.
Click Save.3.
Result: The renamed Profile XML file will be saved in the selected location.
To save an existing Profile using the same location and file name
In Motive, from the File menu, choose Save Profile.
To load a Profile
In Motive, from the File menu, choose Load Profile.1.
Result: The Load Profile dialog box appears.
In the Load Profile dialog box, navigate to where the desired .xml file was saved and click on the2.
file to select it.
