PRIME 41
PRIME 41 Diagram
Product ID
Model number: CAM-CAM-P41
Physical Characteristics
Mounting: 0.635 cm (1/4")-20 tripod thread (x2)
Operating temperature: 0°C to +51°C (32°F to 123.8°F)
Case: Aluminum and Polycarbonate
Width: 12.6 cm (4.96”)
Height: 12.6 cm (4.96”)
Depth: 13.6 cm (5.34”)
Weight: 1.45 kg (3.2 lb)
Lens & Filter
Stock lens: 12 mm F#1.8 (wide band AR coated)
Horizontal FOV: 51°
Vertical FOV: 51°
Adjustable focus and f-stop
850nm band-pass filter
Image Sensor
Resolution: 2048 x 2048
Pixel Size: 5.5 µm x 5.5µm
Frame Rate: 30–180 FPS (adjustable)
Latency: 5.5ms
Shutter type: global
Shutter speed:
Default: 0.5 ms (500 µs)
Minimum: 0.01 ms (10 µs)
Maximum:
