BT Smart Charger
BTSmart Charger Diagram
Size and Weight
Case: Steel
Width: 15.5 cm (6.1”)
Height: 8.47 cm (3.33”)
Depth: 36 cm (14.17”)
Weight: 2440 g (86.07 oz)
Input/Output & Power
Data: Ethernet, USB
Power: 20 Watt
Voltage range: 100V - 240V
Note: BTSmart Charger Rev 6 is built with a momentary contact type power button with the blue LED
that will light up only after the "boot up" is complete. To turn the device power off, press the power
button, then wait until the blue LED light turns off before you disconnect from the power source.
BTSmart Charger Functions
The BTSmart Charger is a device used to recharge the battery of a BTBeacon. BTBeacons are connected
to the BTSmart Charger using the BTBeacon’s USB port. While connected, the BTSystem can read the
status of the battery, regulate charging and maximize battery life. The BTSmart Charger can hold a
maximum of 6 BTBeacons at one time.
BTSmart Charger Configurations
The BTSmart Charger can be configured to either be horizontal and sit flat on a desk, or be vertical and
be mounted on a wall.
