Using Calibration Data to Adjust
Visualization in BTWYSIWYG
Once fixtures have their position calibrated in BlackTrax, this information can be used to improve
visualization in BTWYSIWYG. The position of fixtures in BTWYSIWYG will change to the calibration
locations, creating a more accurate visualization.
To use calibrated fixture positions in BTWYSIWYG
In BlackTrax, open the BlackTrax project file.1.
In BTWYSIWYG LIVE mode, go to the BlackTrax panel.2.
Note: To open the BlackTrax panel if closed, from the Live menu, choose BlackTrax Panel.
Result: The BlackTrax panel appears on the right side of the BTWYSIWYG window.
Select the BTX Mode checkbox.3.
Click Connect.4.
Select the Calibrated Fixture Position checkbox.5.
Result: The position of fixtures in BTWYSIWYG changes to reflect the calibration data created
in BlackTrax.
Note: For details on how to calibrate fixtures, see Fixture Calibration page.
