To use the trackables and beacons widget
In BTWYSIWYG LIVE mode, from the Live menu, choose Trackables and Beacons to open the1.
Trackables and Beacons panel.
Result: The Trackables and Beacons panel appears and displays the list of Trackables,
Beacons, and Frames associated with the connected BlackTrax project.
In the Trackables and Beacons panel, click on the arrow at the far left of the list of Trackables,2.
Beacons or Frame to expand or collapse the corresponding list below them.
On the Trackables and Beacons panel, click on a single or multiple Trackables, Beacons or Frame to3.
select in the Shaded view.
Result: In the Shaded view, the selected Trackable(s) or Beacon(s) or Frames will turn to
white with the corresponding text label identiļ¬cation.
Note: You can activate Shaded View Selection by pressing TAB while in CAD, Design or Live mode >
Shaded View. Once you press TAB, a purple message at the top right-hand corner of the Shaded view
window appears: "Shaded View Select ON", and you may click on the objects in Shaded view to select.
Please refer to the "Using Shaded View Selection" section in the current WYSIWYG Reference Guide.
