Currently Tracking (Green): Select this checkbox to display only the stick beams of the
fixtures connected and actively following a Trackable in a BlackTrax chapter. This stick
beam appears in green color.
Currently Standby (Blue): Select this checkbox to display only the stick beams of the
fixtures that are connected to the system and are set to follow a Trackable in a
BlackTrax chapter. This stick beam appears in blue color.
Unassigned (Yellow): Select this checkbox to display only the stick beams of the
fixtures that are connected to the system but not set to follow a Trackable in any
BlackTrax chapter. This stick beam appears in yellow color.
Select the Enable Message Log checkbox to activate the message logging options.6.
Log To File: Select this checkbox to record the log information and automatically store into a
file in the "bt_run_time" folder of your local drive.
Log Data: Select this checkbox to record the motion tracking information as it is displayed in
the message box.
Clear Log: Click this button to clear the message box.
Viewing LEDs and Centroids in Shaded View
of BTWYSIWYG
How LEDs of a Beacon are displayed in Shaded view:
An LED appears as a solid circle when in front of everything in Shaded view.
An LED appears as a circle outline when behind an object in Shaded view.
An LED appears in the color that is identical to the Beacon color in BlackTrax.
When an LED is selected, its color turns to white and the text label identification appears. For
example, the screenshot (above) shows "L:101.4" which indicates LED of Beacon 101 and LED no.
4.
How Centroids are displayed in Shaded view:
A Centroid appears as a solid square object when in front of everything in Shaded view.
A Centroid appears as a square outline when behind an object in Shaded view.
A Centroid appears in the color that is identical to the Beacon color in BlackTrax.
When a Centroid is selected, its color turns to white and the text label identification appears. For
example, the screenshot (above) shows "C:Whiteboard(101)" which indicates the Centroid
associated with Beacon 101 is patched to the Whiteboard trackable.
When a Centroid is selected, the LEDs associated with the Centroid are automatically selected.
The Centroid appears with only a number if it is not patched to a Trackable.
Using the Trackables and Beacons Widget
The Trackables and Beacons widget is an easier, convenient and faster way to find and select LEDs and
Centroids in the Shaded view of BTWYSIWYG.
