Chapter Configuration
Single Chapter Configuration
The central widget in the Editing View is where you modify Chapters and assign Trackables and Fixtures
to the chapters. The Single Chapter tab is where you modify settings for the currently selected chapter in
the Edit Chapters widget. With a chapter selected in the Edit Chapters widget, you can drag trackables
from the Trackables Library into the top pane of the central widget to assign the trackable to the selected
Chapter. You can also copy/paste Trackables using the "Copy/Paste" buttons, and delete selected
trackables from the selected chapter using the "Delete" button.
When you assign a trackable to a chapter then select the chapter and corresponding trackable you wish
to assign fixtures to, you can drag the desired fixtures from the Fixtures library in the Libraries widget to
the bottom pane of the central widget. You can also possible to copy/paste Fixtures using the
"Copy/Paste" buttons, and delete selected fixtures from the selected trackable/chapter using the "Delete"
button.
Select a fixture in the bottom pane of the central widget and open the Fixture Settings widget to apply
fixture settings.
In the Single Chapter tab, fixtures are displayed in List View or Table View. You can add filters in each
view to display fixtures with specific settings.
Uses Iris: Will show if a fixture uses iris to change the beam size.
Uses Prediction: Will show if a fixture has prediction settings.
Has Offset: Will show if a fixture has any offset settings applied.
Has Following Setting: Will display if a fixture is assigned to follow specific LEDs of assigned
BTBeacons.
Uses LED 1: Will display if a fixture is assigned to follow the LED in BTBeacon port 1.
Uses LED 2: Will display if a fixture is assigned to follow the LED in BTBeacon port 2.
Uses LED 3: Will display if a fixture is assigned to follow the LED in BTBeacon port 3.
Uses Zones: Will show if a fixture uses zoom to change the beam size.
Uses Auto-Spot Mode: Will show if a fixture has Auto-Spot mode settings.
Uses Zoom: Will show if a fixture has any zone settings applied.
Table View displays all fixtures assigned to the currently selected trackable in a table format. You may
configure the columns to display an icon according to the applied fixture settings. The columns are Spot
ID, and Type, followed by any of the settings enabled in the following list:
LED Following
Zoom
Iris
Smooth Pickups
Auto Douse
Sensitivity
Offset
Auto Spot Mode
Zone
Click the Clear Trackable Selection button at the bottom of the top pane of the central widget to clear the
selected individual trackable or all the selected trackables.
