To define boundaries you will have to measure how far the origin of the Space is from the intended
boundary in the Space. This will need to be done for each axes (XYZ). The origin of the Space should be
the same origin as the duplicate Space made in WYSIWYG.
Attention: In Motive, the Z axis represents length and the Y axis represents height. In the rest of
BlackTrax the Z axis represents height and the Y axis represents length. +X also becomes -X in Motive.
Note: Be aware of the -Y setting for your Space. If the origin of the Space is elevated and tracking occurs
below the origin, ensure the value can cover the intended tracking area.
To set the tracking boundary of the space
Open the Reconstruction Properties window. To open the window, from the View menu, choose1.
Reconstruction Properties.
In the Reconstruction Properties window, in the Point Cloud section, under the Reconstruction2.
Bounds heading set the Bound Reconstruction field to True.
Set the Minimum X (meters) field to the distance from the origin of the Space to the intended3.
boundary on the negative (-) X axis (width).
Set the Maximum X (meters) field to the distance from the origin of the Space to the intended4.
boundary on the positive (+) X axis (width).
Set the Minimum Y (meters) field to the distance from the origin of the Space to the intended5.
boundary on the negative (-) Y axis (height).
Set the Maximum Y (meters) field to the distance from the origin of the Space to the intended6.
boundary on the positive (+) Y axis (height).
Set the Minimum Z (meters) field to the distance from the origin of the Space to the intended7.
boundary on the negative (-) Z axis (length).
Set the Maximum Z (meters) field to the distance from the origin of the Space to the intended8.
boundary on the positive (+) Z axis (length).
Close the Reconstruction Properties window.9.
Result: The boundary in your Space will be defined. Tracking is only possible inside this
boundary.
Save the changes to the project file. To save, from the File menu, choose Save Project.10.
