Configuration Data
You can import and export output configuration data to configure the current tracking output or store
tracking output data for later use.
To import output configuration data
From the File menu, choose Import and then choose Outputs.1.
Result: The Browse window appears.
Browse to the .btoc file and open it.2.
Result: The Output Import Details window appears. The table in the Output Import Details
window displays the output configuration settings that will be imported into your project.
In the Output Import Details window, select the checkbox of the following options:3.
Create New: This option will create the new outputs as defined in the New Outputs section.
Delete Existing: This option will delete any outputs in the Deleting Outputs section. These
existing outputs are already present in the BlacTrax project.
Overwrite Existing: The current output configuration defined in the Existing Outputs section
will be replaced with the settings of the output configuration being imported.
Note: The checkbox will only appear if an output being imported has that option (i.e. Check
New will only appear if there are new outputs).
If an output data with the same name is already present in your file, the changes will be4.
highlighted, and you are given the option to overwrite the current output with these new settings.
The Output Configuration data stored in the .btoc is applied to the current project in BlackTrax.5.
To export output configuration data
From the File menu, choose Export and then choose Outputs.1.
Result: The Export Calibration window appears.
Under file type, select if you want to export .btoc.2.
Browse to the folder you wish to save the file.3.
Click Save.4.
Result: All Output Configuration data is exported to the selected folder.
Note: The project file must first be saved before you can export output configurations.
Exporting a Show Report
You can export a show report from the Export menu, which contains all the information regarding the
programming of the show, including chapters, trackables, and Frames.
To export a show report
From the File menu, choose Export and then choose Show Report.1.
The Export Show Report window appears.
Browse to where you would like to save the file and click on Save.2.
Result: The file is saved and contains all project information as of the export in an .html
format.
