Button B : This indicates the current status of the B button on the BTBeacon. The button can be
set to either ON or OFF. This button is used in fixture calibration.
LED BTBeacon Data
LED BTBeacon data is information on the individual Cartesian coordinate position of every LED connected
to the BTBeacon.
LED 1 : The number next to the icon is the identifying numbered pulse of the LED in the
BTBeacon’s port 1.
LED 1 Data : This is the current Cartesian coordinates of the LED in the BTBeacon’s port 1.
LED 2 : The number next to the icon is the identifying numbered pulse of the LED in the
BTBeacon’s port 2.
LED 2 Data : This is the current Cartesian coordinates of the LED in the BTBeacon’s port 2.
LED 3 : The number next to the icon is the identifying numbered pulse of the LED in the
BTBeacon’s port 3.
LED 3 Data : This is the current Cartesian coordinates of the LED in the BTBeacon’s port 3.
