Beacon(s).
Start/Stop: Toggle this button to start or stop the movement.
Pulse: Click this button to trigger a single pulse of movement.
Network Configuration
In this section, the network address and port information linked to the internal IP addresses of the
BTServer are displayed.
Motive Sender: Displays the network address and port information used for sending position data to
the other modules. Unmark the checkbox to disable the connection and stop sending position data.
Router Listener: Displays the network address and port information used for receiving data packets
(such as commands) from the Beacons. Unmark the checkbox to disable the connection and stop
receiving data.
Note: This feature is not currently used.
Router Sender: Displays the network address and port information used for simulating sent data
packets from the Beacons (such as battery status). Clear the checkbox to disable the connection
and stop sending data.
Message Log
In this section, information on data that passes through the Simulator and system events are displayed.
This information can also be saved to a separate file for review later. Message Log files can be found at
C:\bt_run_time.
Display Log Data: Select this checkbox to display detailed packet information in the Message Log.
Write to File: Select this checkbox to save the log as a text file in the C:\bt_run_time folder.
Clear Log: Click this button to clear all messages in the log.
