Stringer
Stringer Diagram
Physical Characteristics
Cable length: 1.37 m (4.5') Custom sizes are available
Cable thickness: 2.9 mm (0.11")
LED Diffuser diameter: 7.93 mm (5/16")
Strain relief: 30 mm (1.18")
Male SMA Connector: 9 mm x 8 mm (0.35" x 0.32")
Male SMA Connector diagram
Stringer Functions
When a Stringer is connected to a BTBeacon LED port, the LED portion of a Stringer will pulse that
BTBeacon’s unique ID signal. The pulse is viewed by BTSensors, sent to the BTServer and used to
calculate the BTBeacon position in the Space.
