Brooks Firetracker FT128 CIE - Local Alarm Acknowledgement (LAA); Table 14 Alarm Acknowledgement Function

Technical / Programming Manual
FT128 Rev 2.2
114
…. during the investigation period (IP):
AAF zone xx, investigation in progress
If more than one AAF zones are activated, only the first is shown in the display.
Notes:
 Maximum number of analogue smoke detectors in an AAF zone is 5.
 Smoke detectors in an AAF zone cannot be programmed as 2-unit-dependent and
not be controlled by the Alert Annunciation function.
 Only Analogue photo electric smoke detector 4401 (4301) and Analogue multi
detector 4400 (4300) can be used for AAF. If the Analogue multi detector 4400 is
used, it must be programmed as type "Two addresses", so that only the "smoke
part" of the detector can be used in AAF function.
 Max. 50 AAF zones (00-49) per C.I.E
 The sounder base 3379 has to be programmed with the trigger condition "AAF
zone alarm" (and other trigger conditions).
14.12.2 Local Alarm Acknowledgement (LAA)
The local alarm acknowledgement is the European’s equivalent of the Australian alarm
acknowledgement facility (AAM). The function is identical to the AAF explained in section
14.12.1 with different terminologies. The functionality of Panasonic’s LAAU versus Brooks
AAM are shown in Table 14 below.
Table 14 Alarm acknowledgement function
Panasonic LAAU
Brooks AAM
Product code
4445
3340
Module’s name
Local Alarm Acknowledgement
Unit LAAU
Alarm Acknowledgement
Module AAM
Function’s name
Local Alarm Acknowledgement
LAA
Alarm Acknowledgement
Facility AAF
Trigger type in EBLWin
LAA
AAFC
No. of zones
Max. 100 LAA zone
Max. 100 AAFC zone
No. of detectors per
zone
5 x 4400/4401 (4300/4301)
5 x 4400/4401 (4300/4301)
Ack. period
10-120 seconds
10-120 seconds
Investigation period
1-9 minutes
1-9 minutes
Sounder unit
3379
3379
Ack. Message on LCD
LAA zone xx, activated
AAF zone xx, activated
Investigation message
on LCD
LAA zone xx, investigation in
progress
AAF zone xx, investigation
in progress
One LAA zone consists of one to five analogue smoke detectors 4400 / 4401 (4300 / 4301),
one LAA buzzer (sounder base 3379) and one Local Alarm Acknowledgement Unit (LAAU).
All connected on the COM loop.
Note: All devices included in an LAA zone must be connected to the same CIE.
The local alarm acknowledgement connection diagram is shown in Figure 42 below.
