6.5.4 Duct Detector Chambers
6377 Duct Detector Chamber UG-4. The housing is made of grey ABS and the venturi
pipe is made of aluminium. It is supplied with four IP65 glands for cable entry.
6377 can be used in conventional as well as Analogue fire alarm systems,
depending on the base and detector mounted inside the housing (base 2324 +
4452 or base 3312 + 4401). The venturi pipe is available with or without a built-in
fan and in three lengths (0.6, 1.5 & 2.8 m). The pipe can easily be shortened to
suit the ventilation duct. Mounting bracket and filters are also available. For more
information see Duct Detector Chamber Datasheet.
