Brooks Firetracker FT128 CIE - Table 2 Control Panel Limitation

Technical / Programming Manual
FT128 Rev 2.2
16
Table 2 Control Panel Limitation
Item
CIE
Fire alarms (presented in the FT128 display as ZONE and/or
ZONE-ADDRESS)
4
256
Number of zones
99
4
Faults
200
External faults
50
Technical warnings
50
Short Circuit Isolators
64
Loop units
255
Trigger conditions (in all the control expressions)
Approx. 1000
Interlocking Combinations
100
3379 + 4477 units
50
Total number of detectors and/or Manual Call Points
512
5
Max. number of AAF zones
50
Max. number of detectors per AAF zone
5
Max. number of I/O Matrix boards with expansion boards.
Number without expansion boards.
4
8
Max. number of expansion boards 4580, 4581 & 4583
6
6
Max. number of outputs per CIE including all kinds of outputs
200
Max. number of inputs
128
Max. number of 4380 units
10
4
Up to 256 ZONEs and/or ZONE-ADDRESSES can be programmed but only the zone numbers 01-99 can be used.
5
Max. number of alarm points per CIE (microprocessor) is 512 (including conventional alarm points) and maximum number of
alarm points per zone is 32. Care must be taken in order not to exceed 512 detectors and/or Manual Call Points connected to
the CIE i.e. 255 COM loop units + 257 conventional detectors / MCP.
6
Expansion boards are internally connected to COM loop 0, ensure total number of expansion boards and I/O matrix boards
connected to the COM loop does not exceed 4. Software 2.1.1 allows to use 4 expansion boards.
