3 Click on the button beside the respective input/output to delete selections.
4 To locate the device from which each input/output has been used, click on the
adjacent button. The device dialog box will appear. This is a time saving
feature when you have close to hundred interlocks specified.
The configured interlocking combination should display the following:
Name: Displayed in the EBLWin Tree and List views. Default is "Interlocking
Combination" that can be edited when required. "Area-Point" will be added in the
tree view and shown in the list view.
Area and Point: Each “Interlocking Combination” is presented as Area-Point
(compare with Zone-Address). Area numbers 1-99 are possible to use and within
each are, Point numbers 1-99 can be used.
Available interlocking outputs list displays all the previous programmed outputs,
Type = "Interlocking".
Available interlocking inputs list displays all the previous programmed inputs,
Type "Interlocking". Select one output and one Input. Press Select and the
selected output and input will be shown in the Selected output and Selected input
field respectively.
It is possible to Remove an output / input (from the field).
It is possible to Find (open the dialog box) an output / input.
Output parent: Shows where the selected output is situated, e.g. Control unit 0.
Input parent: Shows where the selected input is situated, e.g. Control unit 0.
Text = Interlocking text to be shown in menu H9/C1. Can be written in this field or
in the "Texts" dialog box, see chapter "Creating Alarm Texts via EBLWin”, page
120.
Buzzer checked = activated interlocking input will turn on the FT128 buzzer (0.8 /
0.8 sec.)
. The buzzer can be silenced. It will be automatically turned on again,
if a new interlocking input is activated.
Latched output checked = Output reset has to be performed via menu H9/C3.
(Automatically output reset will not take place when the control expression
becomes false.).
Fault checked = Fault detection ON.
Fault Detection Time: If the input is not activated within 5-255 seconds after the
output is activated
, a fault will be generated:
FAULT: Interlocking input AA/PP
Date: MM-DD Time: HH:MM
12.2 Interlocking Indications
One or more activated Interlocking Combinations (interlocking output and/or input) are
indicated in the display in FT128
:
Interlocking input / output activated
See menu H9/C1
Disabled interlocking output is indicated by the LED "Disablements".
Priority order: Fire alarm – Pre-warning - Interlocking - Fault.
After the end of the delay time (if used).
This indication has low priority and will only be shown in the display if there are no fire alarms, faults, disablements, etc.
