Technical / Programming Manual
FT128 Rev 2.2
13
2 Overview
2.1 FT128 CIE
FT128 is a microprocessor controlled intelligent fire alarm CIE intended for analogue
addressable smoke and heat detectors. Also conventional detectors and manual call points
can be used. Programmable inputs, control outputs and I/O units are available. Up to 255
addresses can be connected to FT128 loaded with EBL128 system software ≥ V2.0.x
.
FT128 is designed and assessed to the Australian Standard AS7240.2, AS7240.4 and
NZS4512:2003. The Fire Brigade Panel controls and indicators are incorporated as part of
the faceplate and conform to AS4428.3.
2.2 Expansion Boards
Up to four expansion boards can be mounted in FT128 CIE. The following expansion board
types are available:
8 Relay Outputs Expansion Board
Inputs And Outputs Expansion Board
For more details, refer to chapter “Expansion Boards ”, page 22 and drawings F728, F729
and F731.
2.3 Power Supply
The primary power source is a switch mode power supply 230 V
AC
, 0.6 A / 24 V
DC
, 1.8 A
(40 Watt)
.
The standby power source is a backup battery (2 x 12V). Up to 24 AH batteries can be
fitted in the standard FT128 cabinet.
The batteries and the power supply output are connected to the Main board (4556). See
chapter “Power Supply”, page 171 for more information.
2.4 Software (S/W) Versions
Due to continual development and improvement, S/W versions are being updated from
time to time. The control unit S/W can be updated on site.
2.5 Documents
The following documents are available:
Technical / Programming Manual (this document)
Operation Manual
Connection diagrams
Information found in one document is normally not to be found in another document, i.e.
the documents complement each other. Product Leaflet for FT128 and other units are
available as PDF documents on Brooks web site: http://www.brooks.com.au.
Earlier software versions e.g. Win 128 V1.x.x supports only 128 addresses.
Meanwel power supply 40W is obsoleted and has currently been replaced with 75W
