Brooks Firetracker FT128 CIE - 10 Output Programming; Type of Output; Comments to the Types; Logic

Technical / Programming Manual
FT128 Rev 2.2
81
10 Output Programming
Output programming is done via EBLWin. See the EBLWin dialog box.
10.1 Type of output
The following types are available (see also comments below):
1. Control
2. Fire Ventilation
3. Extinguishing
4. Alarm Device
5. Routing Equipment (Fire brigade TX)
6. Control, neutral
7. Interlocking Output
10.1.1 Comments to the types
1. Default. General (normal) control output
84
2. Used to activate fire ventilation equipment
85
3. Used to activate extinguishing equipment
86
4. Used for OWS or sounders, etc.
87
5. Used for fire brigade TX outputs only
88
6. General (normal control output. No collective disablement and no LED indication.
7. Output used together with a corresponding interlocking input. See chapter
"Interlocking Function”, page 94. Activated outputs are shown in menu H9/C1.
10.2 Logic
The logic is set in the EBLWin dialog box "Voltage or Relay Output".
(•) Normally Open / low normally open relay contact or normally low voltage output.
( ) Normally Closed/high normally closed contact or normally high voltage output
(24V
DC
).
10.3 Supervised / Non-supervised
A voltage output is normally supervised (default). By unmarking this checkbox the voltage
output will be not supervised.
Note: A normally high output cannot be supervised.
84
Collectively disabled via menu H2/B4 (all control outputs). Re-enabled via menu H2/B8.
85
Collectively disabled via menu H2/B4 (all ventilation outputs). Re-enabled via menu H2/B8. LED "Ventilation" is indicating
activated output.
86
Collectively disabled via menu H2/B4 (all extinguishing outputs). Re-enabled via menu H2/B8. LED "Extinguishing" is indicating
activated output.
87
Collectively disabled / re-enabled via menu H2/B9 (all alarm device outputs). Controlled by push button "Silence alarm devices".
Fault on / disabled output is indicated by LED "Fault / Disablements Alarm devices" blinking (fault) / continuous (disablement).
88
Disabled / Re-enabled via menu H2/B10 (Fire and/or fault outputs). Controlled via open door (if programmed so). Used together
with trigger condition Fire brigade TX. LED "Fire brigade TX" is indicating activated output. (Fire brigade TX feedback via a
programmable input can light up the LED instead). Fault on / disabled output is indicated by LED "Fault / Disablements Fire
brigade TX" blinking (fault) / continuous (disablement).
