Brooks Firetracker FT128 CIE - Figure 29 Signal Output Periods; Table 12 Output Signal Period for the Programmable Output

Technical / Programming Manual
FT128 Rev 2.2
83
Figure 29 Signal Output Periods
Delay time, Pulse length, Pulse off and/or De-Activation, have to be set for the "Signal
period" respectively. For types 2 & 5, the x and y times must be equal and maximum 5.6s.
For types 3 & 6 the x time must be maximum 5.6s.
Note: The different types can be used together with the different outputs according to
Table 12 below
Table 12 Output signal period for the programmable output
In FT128
COM loop units
Output
Type
Type
S0-S1
R0
4581
board
4583
board
I/O unit
3361
Unit
3364
Siren, S/B & Beacon
& Light indicator 4477,
3379, 4380 & 4383
4582
board
Inter
locking
1 Steady (continuous)
X
X
X
X
X
X
X
X
X
2 Intermittent
X
X
XXX
--
--
XX
--
--
--
3 One pulse
X
X
XXX
--
--
--
--
--
--
4 Steady (continuous),
delayed activation
X
X
X
X
X
X
X
X
X
5 Intermittent, delayed
activation
X
X
XXX
--
--
XX
--
--
--
6 One pulse, delayed
activation
X
X
XXX
--
--
--
--
--
--
7 Steady (continuous),
delayed de-activation
X
X
X
X
X
X
X
X
--
