Technical / Programming Manual

FT128 Rev 2.2

12.3 Information of Interlocking Combinations (H9)

Menu H9 has the following sub menus.

12.3.1 Activated Interlocking outputs / inputs (H9/C1)

See also chapter “Interlocking Indications”, page 96.

In menu H9/C1 information will be shown as follows:

Output AA/PP activated at HH:MM

Interlocking text.. .. ..

Output AA/PP act HH:MM, input act HH:MM

Interlocking text.. .. ..

Input AA/PP activated at HH:MM

Interlocking text.. .. ..

AA = Interlocking combination Area

PP = Interlocking combination Point within the Area

HH = Hours

MM = Minutes

Use "↑" "↓" to scroll between several interlocking combinations.

12.3.2 Activate / deactivate Interlocking Output (H9/C2)

Even if the control expression for an interlocking output is not fulfilled (true), the output can

be manually activated via this menu.

The "Interlocking Combination" (Area / Point) is to be entered to activate the output. The

corresponding interlocking input will be "monitored" in the same way as if the output was

activated by its control expression.

Reset has to be performed via menu H9/C3.

12.3.3 Reset interlocking output (H9/C3)

Activated interlocking outputs are listed here. Use "↑" "↓" to scroll between the "Interlocking

Combinations" (Area / Point).

Interlocking output activated via its control expression and latching output selected: The

output has to be reset via this menu.

Interlocking output activated via its control expression and latching output not selected: The

output can be reset via this menu.

Interlocking output activated via menu H9/C2: The output has to be reset via this menu.

12.3.4 Disable Interlocking Output (H9/C4)

Interlocking outputs (i.e. Output Type = Interlocking) can be individually disabled via menu

H9/C4. A disabled output will stay in (or return to) the normal condition for the output

respectively. The "Interlocking Combination" (i.e. Area / Point) is to be entered to disable

the output.

All the interlocking outputs can be disabled collectively via menu H2/B4.
