Brooks Firetracker FT128 CIE - Comments to the Trigger Conditions (Functions)

Technical / Programming Manual
FT128 Rev 2.2
87
10.5.1.5 Comments to the Trigger Conditions (Functions):
Alarm
1. Fire alarm. For more information regarding fire alarm, see FT128 Operation
Manual. Output is activated when the specified Zone is in alarm.
2. See 1. Output is activated when the specified alarm point is in alarm.
3. See 1. Output is activated when any alarm point or Zone is in alarm.
4. See 1. Quantity (1-9): "1" means one unit in alarm is required, "2" means two units
in alarm are required to activate the output and so on.
5. Pre-warning.
90
Output is activated when the specified Zone exceeds the pre-
warning level. For more information regarding pre-warning, see FT128 Operation
Manual.
6. See 5. Output is activated when the specified alarm point exceeds the pre-warning
level.
7. See 5. Output is activated when any alarm point or Zone exceeds the pre-warning
level.
8. See 5. See also 4 above regarding "Quantity".
9. Heavy smoke / heat alarm. Output is activated when the specified Zone exceeds
the heavy smoke / heat level. For more information regarding heavy smoke / heat
alarm, see FT128 Operation Manual.
10. See 9. Output is activated when the specified alarm point exceeds the heavy
smoke / heat level.
11. See 9. Output is activated when any alarm point exceeds the heavy smoke /
heat level.
12. See 9. See also 4 above regarding "Quantity".
13. Output is activated when only one address (in two- address dependence) is in fire
alarm state. For more information, see FT128 Operation Manual.
14. Output is activated when only one zone (in two-zone dependence) is in fire alarm
state. For more information, see FT128 Operation Manual.
15. Output activated when "Multiple detector alarm" is true, i.e. Fire Alarm Type A
91
.
16. Output activated when "One detector alarm" is true, i.e. Fire Alarm Type B
91
.
17. General Key cabinet alarm activated. For more information, see FT128 Operation
Manual.
18. Alarm Acknowledgement Facility, requires Alarm Acknowledgement Module
AAM. "Alarm" is activated in the specified AAF zone. Panasonic new Local Alarm
Acknowledgment (LAA) is typically Brooks AAM.
19. Output activated for any "Quiet alarm" in the specified zone. Normally used in
AS1668 fire fan applications or as a non-latching / non-brigade call detector.
20. Output activated for one specified "Quiet alarm" in the specified zone-address.
Used in AS1668 fire fan control applications.
21. This control expression is true (i.e. output activated) for 15 seconds after the last
alarm is reset.
22. Output of specified Zone-Address is activated for predetermined time (set in
EBLWin system properties). Typical application when a smoke detector is
90
The trigger condition is true as long as the pre-warning level is exceeded. It is also true as long as the fire alarm level is exceeded
even if the option pre-warning detection is disabled (via EBLWin).
91
See Section ”Fire Alarm Type A and Fire Alarm Type B”, page 115.
