Technical / Programming Manual
FT128 Rev 2.2
152
Figure 55 Example Setting for National Holidays
The example in Figure 55, the first row is selected (blue marked). Two "National Holidays"
are marked to recur the same date every year.
Note: The National Holidays list has to be updated when the last date in the list is passed.
19.3.6 Two zone dependence
See also chapter "2-zone dependence", page 108.
Default for all zones is no two zone dependence.
Note: Normally, only conventional zones (i.e. Zone Line Inputs with conventional
detectors) should be used for two-zone dependence. For analogue / addressable
detectors the two-address (unit) dependence should be used.
Ten (1-10) groups are available.
For each group, write the zone numbers for the two-zone dependent zones (min. two
zones!!!) in the white field/line. Use comma as punctuation mark between the zone
numbers or a sequence (e.g. xxx-yyy).
Note: Check so that two or more zones are programmed in each group. (A single zone
in a group will never be able to activate any fire alarm!)
19.3.7 Zone groups
Thirty zone groups are available as shown in the figure below. The default name zone
group 1 – 30 can be changed to provide more descriptive names.
