Technical / Programming Manual
FT128 Rev 2.2
159
When the download is completed the following information will be shown:
Download completed successfully
Control unit will now restart
After the restart, another text message will be shown in the display:
FAULT: Restart, code 25 addr 0
Date: DD-MM Time: HH:MM Serviced
Code 25 indicates a normal restart after a successful SSD download. Acknowledge the
restart fault.
If the download was not successful another fault will be generated.
FAULT: Site specific data (SSD)
Date: DD-MM Time: HH:MM
This text message means that the SSD have not been downloaded successfully i.e. a new
download has to be performed.
20.3 User definable text messages download
Each alarm point, zone and zone line input can have a unique user definable alarm text
programmed via EBLWin. When a fire alarm is activated (e.g. an addressable alarm point),
the presentation number (Zone - Address) will be shown in the control unit display together
with its alarm text.
All alarm texts, up to 40 alphanumeric characters each, are created and downloaded
(included in the site specific data – SSD) via EBLWin.
A fault message for an alarm point, zone or Zone Line Input will also show the alarm text.
