Technical / Programming Manual
FT128 Rev 2.2
155
Validate...: The SSD can be validated at any time, i.e. checked for System Errors,
Warnings and violations. A validation will automatically be done before download of SSD
to FT128. System Errors have to be corrected before the download can start.
Log on control unit: Log on / Log off to an FT128
.
Synchronize…: (When connected and logged on to an FT128.) Data (i.e. faults,
disablements, etc.) will be synchronized, i.e. the data / information are identical in both the
control unit and EBLWin.
Download SSD…: (When connected and logged on to an FT128) opens a dialog box for
download of SSD to the FT128 control unit, the Web-server and connected "Display Units"
(e.g. 1728).
Backup SSD ("Upload")…: (When connected and logged on to an FT128). Opens a dialog
box for backup ("upload") of SSD from FT128 and connected "Display Units" to EBLWin.
Verify SSD…: (When connected and logged on to an FT128.) The SSD shown in EBLWin
will be compared with what is actually stored in FT128. If they are the same the checksums
= same SSD.
Erase SSD…: (FT128 must be in boot mode.) The SSD stored in the FT128 control unit
will be erased. Also the SSW (see Operation Manual) will be erased. NOTE! An EBLWin
key is required.
Reset user passwords…: (When connected and logged on to an FT128.) If any password
has been changed via the control unit menu (H10) or via a Web-server, it will be reset to
the password downloaded via the SSD, i.e. the passwords in the EBLWin dialog box "User
data" (found in the menu "System").
Download Software…: (When connected and not logged on to an FT128.) NOTE! An
EBLWin key 5094 is required. Opens a dialog box for download of an EBL128 S/W file
(xxx.bin) to an FT128 control unit. (There is one .bin file for each convention).
Download EPU/AAU software: (When connected to a Display Unit – via RS232.) For
download of S/W (xxx.bin file) to one Display unit. NOTE! An EBLWin key 5094 is required.
Options…: EBLWin settings. A Convention (one for each country) is selected the very first
time EBLWin is opened. Can be changed if Level 2 is selected, see below. Display Unit
language can be selected as well as the EBLWin language.
Advanced Functions: Can be one of the following alternatives
No "Level" selected (default): Alarm algorithm parameters cannot be changed.
"Level 1" selected: All alarm algorithm parameters, except the fire alarm
parameters can be changed.
Log on require the PC to be physically connected to FT128 and an EBLWin key 5094 plugged in the PC.
