Technical / Programming Manual
FT128 Rev 2.2
75
17. Activated input will light up the LED "Extinguishing" on the front membrane.
(Normally the LED will be lit when a corresponding output is activated.) Output
with trigger condition "Extinguishing system released" will be activated.
18. External fuses (for the external power supply equipment) fault output will generate
a fault in FT128. The following fault message will be shown:
FAULT: External fuses
19. External power supply equipment fault output will generate a fault in FT128. The
following fault message will be shown:
FAULT: External power supply
20. Activated input will generate a fault in FT128. The following fault message will be
shown:
FAULT: Fault warning routing equipment
21. A special detector, push button, etc. can activate a fire alarm in FT128. Zone no.
and Address (+ user definable text).
22. A feed-back from the equipment activated by the corresponding interlocking
output. Activated input is shown in menu H9/C1. See also chapter “Interlocking
Function”, page 94.
23. Fault output "Loss of the battery charger to external power supply equipment" will
generate a fault in FT128. It will have the same time delay, as set for the "Loss of
main power source" fault for FT128. The following fault message will be shown:
FAULT: Charging ext. power supply
24. Fault output "Loss of main power source to external power supply equipment" will
generate a fault in FT128. It will have the same time delay, as set for the Loss of
main power source fault for FT128. The following fault message will be shown:
FAULT: Mains, ext. power supply
25. Default, no programmable input is selected.
26. Used for the "outside switch" (i.e. the New Zealand FB Silence switch).
Turned on: Alarm devices and the CIE buzzer will be disabled. The following fault
message will be shown:
FAULT: FB Silence switch
From Turned on to Turned off: All fire alarms will be isolated, all zones in alarm will
be disabled, alarm devices and the CIE buzzer will be re-enabled and the fault will
be serviced.
27. Pre-warning, e.g. from a High Sensitive Smoke Detector's pre- warning output.
Zone no. and Address set to the same as the corresponding fire alarm (from the
same detector).
28. A technical warning is neither an alarm nor a fault. It is activated as long as the
input is activated, which is indicated by a blinking symbol in the display.
Identified via menu H4/U6. Output with trigger condition "Technical warning
(+name)" will be activated.
29. The Addressable multipurpose I/O unit 3361 monitored input "In0" used as Zone
Line Input (Z) for conventional detectors. Use End-Of-Line capacitor with value
470nF.
