AVEA ventilator systems 7
L2786 Rev. M
Chapter 2: Unpacking and Setup
Ventilator Assembly & Physical Setup
Unpacking the Ventilator
The AVEA is designed for simplicity of operation and set-up. It requires minimal assembly on site.
Items Required for Ventilator Setup
You will need the following to setup your AVEA ventilator:
• Power Source. The ventilator operates from a standard 100, 110, 220, or 240 VAC power source or an optional external
24VDC battery. There is an internal battery supplied with the ventilator, which will operate the ventilator for short periods
(see “Chapter 8: Maintenance and Cleaning”).
CAUTION
The ventilator should be connected to a mains AC power supply for at least 4 hours prior to switching to internal
battery power. For operation on external battery the ventilator should be connected to a mains AC power supply for at
least 12 hours with green LED lot to insure a fully charged battery.
• Pressurized Oxygen, Air or Heliox Gases. The compressed gas sources must provide clean, dry, medical grade gas
at a line pressure of 20 to 80 PSIG (1.4 to 5.6 bar).
Air or Heliox Supply
Pressure Range: 20 to 80 psig (1.4 to 5.5 bar) (Supply Air)
20 to 80 psig (1.4 to 5.5 bar) (Supply Heliox - 80% / 20% Heliox Only)
3 to 10 psig (0.2 to 0.7 bar) (Compressor Air)
Temperature: 5 to 40°C (41 to 104°F)
Minimum Flow: 80 L/min at 20 psig (1.4 bar)
Air Inlet fitting CGA DISS-type body, No. 1160 (Air). NIST fitting per BS-5682:1984 (Air) also available.
Heliox Inlet fitting CGA DISS-type body, No. 1180 (Heliox)
Note:
NIST fittings for air and oxygen are available from CareFusion upon request at the time of the order.
Oxygen Supply
Pressure Range: 20 to 80 psig (1.4 to 5.5 bar) (Supply Oxygen)
Temperature: 5 to 40º C (41 to 104º
F)
Humidity: Dew Point of gas should be 1.7º
C (3º
F) below the ambient temperature (minimum)
Minimum Flow: 80 L/min at 20 psig (1.4 bar)
Inlet Fitting: CGA DISS-type body, No. 1240. NIST fitting per BS-5682:1984 (O
2
) also available.
