CareFusion AVEA - Neonatal Patient Circuit; Front Panel Connections

AVEA ventilator systems Chapter 2: Unpacking and Setup 17
L2786 Rev. M
Standard
Neonatal Patient Circuit
The Neonatal Patient Circuit is attached as
shown in Figure 2–18.
Figure 2–18: Neonatal Patient Circuit
Front Panel Connections
Figure 2–19: AVEA Front Panel Configurations Standard & Comprehensive
Inspiratory Limb
of Patient Circuit
Comprehensive
