Mains Fuses
The main AC power fuses are housed within the power entry module located on the back panel. They are slow blow-
type. Check that the correct voltage for your mains supply is showing through the window in the power entry module.
Table 8–1: Mains fuses
Line Voltage Fuse Amperage
100/120VAC
250V 6.35 x 31.75mm
3.2A
230/240VAC
250v 6.35 x 31.75mm
1.5A
Replacing a Mains Electrical Fuse
WARNING
Ensure that the mains power cord is unplugged before attempting to remove or replaces fuses.
To replace mains electrical fuses:
1. Unplug the ventilator from the mains AC power source and unplug the power cord from the power entry module on the
rear of the ventilator.
2. Using a small flat blade screwdriver, pry open the cover of the power entry module.
