AVEA ventilator systems Appendix B: Specifications 209
L2786 Rev. M
Humidity: 0 to 95% RH non-condensing
Barometric Pressure
Barometric pressure is measured by an internal barometer automatically. This data is displayed as a monitor value on
the setup screen.
Range: 760 to 545 mmHg
Physical Dimensions
Overall Size
Ventilator 17” W x 16” D x 10.5” H or (43.2 cm X 40.6 cm X 26.7 cm)
UIM 16.25” W x 2.5” D x 13.75” H (41.3 cm X 6.4 cm X 34.9 cm)
Weight
Ventilator w/ UIM no compressor < 73 lbs. (33.1 kg)
Ventilator w/UIM and Compressor <
80 lbs (36.3 kg)
Accessories
Pall Microbial Filter
Resistance
The exhalation filter supplied with your AVEA ventilator is manufactured by Pall Medical of Ann Arbor, MI, USA. The
published maximum resistance of this filter is 4cmH
2
O at 100 L/min for the 725 filter.
Compliance
The compliance for the filter is < 0.4 ml/cmH
2
O.
Materials
Materials used in the construction of the filter have passed USP Class VI 121° C Plastic and Cytotoxicity test.
For further information please contact Pall Medical.
Water Trap
Resistance
The resistance of the internal exhalation water trap assembly including the collection bottle is < 0.5 cmH
2
O at 50 L/min.
Compliance
The compliance of the internal exhalation water trap assembly including the collection bottle is < 0.2 ml/cmH
2
O.
