CF MOTO ZForce 950EX - Oil Pump; Second Cylinder Timing Chain

05-147
05 Engine
5.6.9 Second Cylinder Timing Chain
Put timing chain
1
into crankcase from
second cylinder. Set it on crankshaft timing
sprocket. Hook it to prevent it from falling
down.
Install tensioner plate
2
from second
cylinder. Apply 243 thread locker and
install tensioner plate screw
3
.
Tighten torque: 8N•m~12N•m.)
Install chain guard
4
.
5.6.10 Oil Pump
Apply some engine oil on oil pump outer
rotor
1
.
Install oil pump outer rotor
1
.
Install roller needle
2
.
Install oil pump inner rotor
3
in the
direction of arrow on oil pump shaft
4
.
Turn inner rotor
3
until roller needle clips
into the groove on inner rotor.
Install oil pump shaft
4
with inner rotor on
MAG crankcase (with appropriate angle).
Install oil pump cap
1
.
Install bolts
2
.
Install washer
1
.
Install roller needle
2
.
Install oil pump gear
3
(the roller needle
should clip into the groove on oil pump
gear).
Install new circlip
4
.
NOTE: The removed circlips can not be
reused. Replace with new ones during
installation.
3
2
4
1
432
1
2
1
43
2
1
0510301
0510302
0510303
0510304
